处理器 | Intel Xeon E3-1505M V5 (4 x 2.8 GHz, 8MB cache, 45W) |
COM Express Type 6
第6代处理器
PCI Express Gen 3
尺寸 95 x 125 mm
产品规格 | COM Express Basic |
处理器 | Intel Xeon E3-1505M V5 (4 x 2.8 GHz, 8MB cache, 45W) |
内存 | 2 Sockets, SO-DIMM DDR4 up to 2133 MT/s and 32GByte dual channel |
网络 | Intel i219-LM GbE LAN Controller with AMT 11 support |
输入/输出接口 | 8 x PCI Express GEN 3.0 lanes |
图像 | Intel Gen9 HD Graphics Engine |
康佳特板载控制器 | Multi Stage Watchdog | non-volatile User Data Storage | Manufacturing |
嵌入式BIOS | 8/16 MByte serial SPI firmware flash |
TPM | The conga-TS170 can be optionally equipped with a discrete ”Trusted |
电源管理 | ACPI 4.0 with battery support |
操作系统支持 | Microsoft Windows 10 |
温度 | Standard |
湿度 | Operating: 10 to 90% r. H. non cond. / Storage 5 to 95% r. H. non cond. |
尺寸 | 95 x 125 mm (3.74" x 4.92") |
